The automatic circular batch fryer is a fryer with automatic feeding and discharging functions. The automatic discharging fryer can use electricity and gas as the heating energy source. The batch frying equipment is smokeless, multi-functional, oil-water mixed frying equipment. It is easy to operate, easy to maintain, easy to clean, and saves consumption equipment. It can use alone as fried chicken machine or in a fried food production line, such as chin chin production line. Therefore, the commercial batch fryer is suitable for small, medium, and large food processing plants.
Components of the automatic circular batch fryer
The automatic circular batch fryer is made of all 304 stainless steel. It consists of an automatic conveying system, a lifting system, a stirring system, and an oil temperature control system. The machine can add an automatic feeding system according to the customer’s needs to realize full automatic frying.
When the round batch fryer runs, the automatic feeder will automatically turn over and pour the material into the fryer. And it is rotated by the driving motor of the mixer to heat the materials evenly. After completing heating, the machine will stop heating, and the round batch fryer is raised to filter the oil for the first time. After filtering the oil, the fryer is turned over to pour out the materials.
Features of the commercial circular batch fryer
- Automatically discharging, reducing the labor intensity of workers, and controlling the frying quality of fried food;
- Automatic stirring, to ensure even fried food and prevent the sticking of raw materials;
- The commercial deep batch fryer’s automatic deoiling function ensure the taste of the product and reduce production costs;
- Automatic temperature control effectively controls the frying time of food and prevents the phenomenon of over-frying.
Round automatic batch frying machine parameters
Electric heating machine
| Model | Size(mm) | Weight(kg) | Power(kw) | Capacity(kg/h) |
| TZ1000 | 1400*1200*1600 | 300 | 36 | 100 |
| TZ1200 | 1600*1300*1650 | 400 | 48 | 150 |
| TZ1500 | 1900*1600*1700 | 580 | 60 | 200 |
Gas heating machine
| Model | Size(mm) | Weight(kg) | Power(kcal) | Capacity(kg/h) |
| TZ1000 | 1700*1600*1600 | 600 | 150,000 | 100 |
| TZ1200 | 1900*1700*1600 | 700 | 200,000 | 150 |
| TZ1500 | 2200*2000*1700 | 900 | 300,000 | 200 |
Supporting machine
The automatic circular batch fryer can combine with a pneumatic feeder, an upper/lower discharge de-oiler, and a drum seasoning machine to form a simple production line. The simple production line can reduce production costs while meeting the requirements of production output.
